Place of Origin : Guangdong, China
Brand Name : HYD
MOQ : 1
Weight : 3200 kg
Voltage : 380 V
Power : 27 kW
Wire Size : Low-carbon Steel: 2-6mm, High-carbon Steel: 1-4mm
Servo Motors : 12 axes
Max Wire Speed : 100 m/min
Wire Feed Roller : 4 Pairs
Maximum Error : ±0.15 (Length)
Control System : 1SET
Decoiler : 300KG
Servo Motor Power : 21.5KW
Shortest Angel Length : 4 Times Wire Diameter
Power Supply : 380V±10%V50Hz
Machine Dimension : L1100*W1450*H2000MM
Motor Brand : Sanyo
| HYD-42T-12A/13A | ||||
| Multi-function Computer Spring Machine | ||||
| Technical specification | ||||
| Model | HYD-42T-12A | HYD-42T-13A | ||
| Wire Size | Low-carbon Steel2-6mm High-carbon Steel:1 -4mm | Low-carbonSteel:2-6mm High-carbonSteel:1-4mm | ||
| Servo Motors | 12 axes | 13 axes | ||
| Lead Rail | tineraries 120mm | tineraries 120mm | ||
| Wire Feed Roller | 4 Pairs | 4 Pairs | ||
| Maximum error | ±0.15(Length) | ±0.15(Length) | ||
| Max Wire Feed Speed | 100m/min | 100m/min | ||
| Control System | 1SET | 1SET | ||
| Decoiler | 300KG | 500KG | ||
| Reducer | 10PCS | 11PCS | ||
| Servo Motor Power | 21.5KW | 27KW | ||
| Motor Brand | Sanyo | Sanyo | ||
| Shortest Angel Length | 4 Times Wire Diameter | 4 Times Wire Diameter | ||
| Power Supply | 380V±10%V50Hz | 380V±10%V50Hz | ||
| Machine Dimension | 2500KG | 3200KG | ||
| Machine Size | L1100*W1450*H2000MM | L2100*W2050*H2000MM | ||














|   |
| Automatic 12 Axes CNC Spring Machine with 1-4mm Wire Capacity and 100m/min Speed for High Efficiency Images |
